Product Specifications
| Model | W10 |
|---|---|
| Bulb Model | 1000W LED White Light Module |
| Color Wheel | 4 Fixed Color Filters + CRI Filter + Warming Filter + Open (White Light), CMY + CTO;CTO |
| Gobo | Rotating Gobo Wheel: 6 Interchangeable Gobos +Open (White Light) LOGO Disc Outer |
| IP Level | IP54 |
| Size | N.W: 38.76 kg |
- Product Description
- Download
The W10 is a high-power 1000W LED professional profile moving head light with a maximum 41952lm luminous flux and 70°–51° zoom range. It features precise CMY color mixing and 2000K–7400K CTO temperature adjustment, paired with fixed and interchangeable rotating gobos, reversible four-facet prism, linear frost and mechanical iris. Equipped with a 4-blade 180° rotatable cutting system and high-precision magnetoelectric positioning, it supports mechanical dimming, DMX512 and RDM remote control. Boasting IP54 waterproof rating and USB upgrade function, it delivers stable and versatile lighting for theatres, studios and large-scale events.
Model:W10
Channel Modes: 37CH/38CH/41CH
Light Source: 1000W LED White Light Module
Source CTO: 8400K
Fixture Output CTO:7049K
Light Source Lifespan: 20,000 hours
Fixture Output Luminous Flux: 41,952 Im
@10m: Minimum Angle Illuminance: 12,861 lux,
Minimum Spot Diameter: l.18mMaximum Angle
Illuminance: 368 lux, Spot Diameter: 10m
Beam Aperture: 130mm
Zoom Angle:70-51°
Input Voltage: AC 110-240V
Frequency: 50/60Hz
Current: 11.54A (110V),5.77A (220V)
Power Consumption:1270W
Power Factor: PF ≥0.95
Display: 2.8-inch Blue LCD Screen,reversible 180°
Color Wheel: 4 Fixed Color Filters + CRI Filter + Warming Filter + Open (White Light), CMY + CTO;CTO
Color Temperature: 2000-7400K linearly adjustable
Fixed Gobo Wheel: 8 Gobos +1Open (White Light)
Rotating Gobo Wheel: 6 Interchangeable Gobos +Open (White Light) LOGO Disc Outer
Diameter: 27mm, Effective Area: 19mm, Thickness: 1.lmm)
Prism:1 Four-facet Prism, reversible rotation
Frost: Linear Frost Effect
Iris: Mechanical Linear Iris, adjustable spot sizeSshutter/cutter: Four -blade Full-frame Graphic Cutter Module, profile patterns rotatable 180°
Dimming: 0-100% Mechanical Dimming, Search/Reset Magneto electric Positioning System for higher precision, reliability, and performance.
UsB: Supports address code setting without power;external interface for software upgrades
Protocol: DMX512, supports RDM protocol, allows remote address code setting via console
Positioning Technology: High-precision Magneto electric Positioning System for more accurate x/ Axis positioning
Pan: 540°;8Bit/16Bit
Tilt: 270°;8Bit/16Bit
IP Rate: IP54
Product Size: 426x 300x 772 mm
N.W: 38.76 kg
W10-PROFILE
