37*40W RGBW LED WASH

The LM940 is a professional LY380W moving head beam light with 8127lm luminous flux and ultra-high 164255lux illuminance at 10 meters. It features adjustable zoom angles, 9 color filters, fixed and rotating gobos, plus dual bidirectional rotating prisms and frost effect. Adopting 0-100% mechanical dimming and variable-speed strobe with macro functions, it supports DMX512 and RDM remote control. Equipped with 180° reversible touch screen and precise opto-reset positioning system with 540° pan and 270° tilt, this lightweight fixture delivers stable and rich dynamic lighting for stages, concerts and entertainment venues.

Model: LM940

Channel Mode :22CH/36CH/133CH/147CH/170CH

Light source: 37 x 40W RGBW LED

Light source CTO: 2700 - 10000K

Light source lifespan: >20,000 hours *Data provided by the light source supplier

Illuminance at 10 meters (minimum/maximum light spot): 8180 lux /2.68m, 820 lux /11.1m

Fixture output luminous flux: 23000lm

Beam angle: 15°-48°

Input voltage: AC100-240V

Frequency: 50/60Hz

Current: 35A (100V), 6.14A (220V)

Power: 1350W

Power factor: PF > 0.95

Display: 8-inch LCD color touchscreen, can be rotated 180°

Control methods: Supports DMX512 mode, RDM mode, and self-running mode;

Dimming: 0-100% mechanical dimming;Signal input ports: 3-pin + 5-pin;

Pan: 540°; 8Bit/16Bit

Tilt: 270°; 8Bit/16Bit

IP protection level: IP20;

Product size: 465x 367x 492 mm

NW: 23KG
